1. What are PLDs?
PLDs (Programmable Logic Devices) are electronic components used to build digital circuits. Unlike fixed-function chips, PLDs can be programmed to perform specific tasks after they are manufactured.
Types of PLDs:
-
SPLD (Simple PLD):
-
Small, simple chips.
-
Includes PAL (Programmable Array Logic) and GAL (Generic Array Logic).
-
Used for small logic tasks.
-
-
CPLD (Complex PLD):
-
Bigger and more powerful than SPLDs.
-
Can handle medium-level logic tasks.
-
Contains multiple logic blocks connected together.
-
2. What is an FPGA?
FPGA (Field Programmable Gate Array) is a special type of PLD. It is larger and more flexible than SPLDs or CPLDs.
Key Features:
-
Contains thousands of logic blocks.
-
Can be reprogrammed as many times as needed.
-
Used in advanced systems like telecommunications, automotive, medical devices, and AI.
Why is it called “Field Programmable”?
Because it can be programmed after it’s shipped (i.e., “in the field”), not just in the factory.
3. PLD vs FPGA – Key Differences:
| Feature | PLD (SPLD/CPLD) | FPGA |
|---|---|---|
| Complexity | Low to medium | High |
| Number of Gates | Thousands | Millions |
| Reprogrammable | Usually once (some many times) | Yes, many times |
| Speed | Generally faster for small tasks | Can be slower but highly flexible |
| Use Cases | Simple logic, timing circuits | Complex systems, real-time processing |
| Cost | Lower for simple designs | Higher, but cost-effective for large designs |
4. How Do They Work?
PLDs and FPGAs are built with programmable logic gates. These gates (like AND, OR, NOT) are combined to perform desired logic functions.
-
In PLDs: A simple configuration table (like a truth table) tells how inputs are connected to outputs.
-
In FPGAs: A more complex setup using CLBs (Configurable Logic Blocks), switching matrices, and I/O blocks creates flexible logic paths.
5. Programming PLDs and FPGAs
They are usually programmed using HDL (Hardware Description Language) such as:
-
VHDL
-
Verilog
The code describes how the circuit should behave, and tools compile it into a format the device can understand.
6. Applications
| Area | Example Use |
|---|---|
| Consumer Electronics | Smart TVs, Game Consoles |
| Automotive | Engine control, Safety systems |
| Telecom | Routers, Signal Processing |
| Medical | Diagnostic devices |
| AI & Machine Learning | Accelerators for neural nets |
7. Summary
-
PLDs are programmable chips used to build digital circuits.
-
FPGAs are advanced PLDs that offer high flexibility and are used in complex systems.
-
They allow custom hardware design without creating a custom chip from scratch.
-
Learning HDL is essential to work with them.
-
They are key tools in modern electronics and embedded systems.
